With HTML5 support, create a digital signage kiosk can be easier with IAdea media player.
IAdea media players are compatible with all USB interface single-touch screens that use standard HID driver. For multi-touch displays, following are list of models that are known to be compatible:
|
IAdea player models*: |
|||||||
| Brand | Model no. | VID | PID | Single-touch | Multi-touch | Zoom In/Out | Hot plug |
| Viewsonic | 32”PCT | 222A | 0001 | ○ | ○ (ten fingers) | ○ | ○ |
| Viewsonic | 70”PCT | 222A | 0001 | ○ | ○ (ten fingers) | ○ | ○ |
| Viewsonic | CDE5560T | 1FF7 | 0001 | ○ | ○ (ten fingers) | ○ | ○ |
| Viewsonic | CDE8451-TL(1080P) | 1FF7 | 0001 | ○ | ○ (six fingers) | ○ | ○ |
| Viewsonic | CDE8451-TL(4K2K) | 1FF7 | 0001 | ○ | ○ (six fingers) | ○ | ○ |
| IRTouch | FB/FC-series | IFF7 | 0013 | ○ | ○ (ten fingers) | ○ | ○ |
| AOC | ○ | ○ | ○ | ○ | |||
| Samsung | D-series | ○ | ○ | ○ | ○ | ||
| ELO | 3202L | 04E7 | 240B | ○ | ○ | ○ | ○ |
| ELO | 4202L | 04E7 | 240C | ○ | ○ | ○ | ○ |
| SamSung | LH32PMFXTBC/XY | 0x04E8 | 0x20A6 | ○ | ○ | ○ | ○ |
Following are the touchscreens that share same VID&PID with above tested displays. They shall be also compatible with IAdea media player: (How to find out the VID and PID for my touchscreens?)
| Brand | Model no. | VID | PID |
| ViewSonic | CDE5501-TL | 1FF7 | 0001 |
| ViewSonic | CDE5561T | 1FF7 | 0001 |
| ViewSonic | CDE6552-TL | 1FF7 | 0001 |
| ViewSonic | CDE6560T | 1FF7 | 0001 |
| ViewSonic | CDE6561T | 1FF7 | 0001 |
| ViewSonic | CDE7051-TL | 1FF7 | 0001 |
| ViewSonic | CDE7060T | 1FF7 | 0001 |
| ViewSonic | CDE7061T | 1FF7 | 0001 |
| ViewSonic | CDE7561T | 1FF7 | 0001 |
| ViewSonic | CDE8452T | 1FF7 | 0001 |
| ViewSonic | CDP4260-TL | 202E | 0006 |
| Philips | 43BDL4051T (10-poiint IR touch) | 1ff7 | 0013 |
| Philips | 55BDL4051T (10-poiint IR touch) | 1ff7 | 0013 |
| IRTouch | TC-series | 1FF7 | 0013 |
*Device firmware may need to update to latest release to support all touch displays listed above.
